A leading co-working space provider increased its BIM designing efficiency by 25% while working with us

About Client:

The client is a leading company in co-working space providing solutions for commercial office space to minimize the headaches of upfront investment and long leases. They provide a flexible real estate platform that allows using personal space on your terms.

With supreme flexibility to spaces made for health and safety, the client helps big companies improve their real estate portfolio with worldwide scale, suitable terms, and speed to market.

Summary/Project objective:

Multiple departments in the client organizations had different objectives from this project. Management wanted to minimize the leakage in the system and standardize the ROI based on the seating capacity of the office space. Design teams wanted standardization of the models so that they can run different automation and link the Revit data to their ERP systems.

The sales team wanted flexibility in the Revit model so that they can have customer-focused sales drawings (With lounge, pantry, Reception, etc.) instead of management-focused drawings which count the number of sellable desks in the office space.

Above all everyone wanted a single source of truth that all teams can refer to.

Business challenge/ The Goal:

  • The client wanted to complete the project within 6 months including the necessary approvals from their Product Compliance team.
  • A large number of quality checks need to be performed before acceptance.
  • Teams had to rely on multiple sources of information to create the final model.
  • The system should work in tandem with the existing system and a lot of historical data associated with room numbers needed to be retained for continuity.
  • The client also needed to remove unwanted elements from the models.
  • The client required exact numbers for rooms according to floor plans and further needed tags for missing rooms according to specified standards.

Solution:

  • nCircle Tech has completed a project of updating 2500+ floors wherein each floor took 15000+ hours of man work in just 6 months with utmost accuracy. Because of automation, we helped the client to increase productivity by 20-25%.
  • We, nCircle Tech, have offered a few highlighted solutions like BIM Modeling Services and BIM Automation for completing tasks of the client.
  • We helped to find a solution by ramping up to a team of 15 modelers within 2 weeks. We developed automation solutions to speed up the process and also automated quality checks for saving time.
  • We used BIM Connections for automatically downloading files from BIM 360 to Google Drive and also established a solution to automatically update Revit models from 2017 to 2020.
  • We also have set quality checks for desk count, the number of rooms, auto-tagging of rooms, and automatically exploding grouped families into separate BIM entities, and floor-wise DWG export for all Revit files collaborated on BIM360.
  • We, at nCircle, have our USP in developing BIM Automation along with offering BIM Modeling Services, which in turn helped in reducing 25% of the total project time and cost.
  • nCircle developed a set of Automation tools like identifying the number of desks/floor and giving the desk count automatically, number of rooms on each floor, Auto-tagging rooms, and (automatically….. BIM360).
  • We have also implemented a set of quality checks which could help verify the output of the automation against the manually worked areas and identify the difference if any.

Benefits:

  • With our Design and QC Automations, we delivered the project output much faster.
  • Higher productivity with a unique blend of Modeling + Automation
  • Pre-built Model rule checker and automation of nCircle Tech saved hundreds of manual hours for the project
  • Automatic checking (Quality check automation) improved overall Quality

Impact:

  • Management can now track sellable desks more efficiently and it will help in improving the top line of the organization.
  • The sales team can maintain attractive-looking floor plans for customer showcases.
  • All data present in the Revit files is easy to process since all the files follow the consistent standard.
  • Increased the overall efficiency by 25%

Conclusion:

The benefits of our automation services led clients to come up with additional project work within the scope of further automation improvements in their legacy systems. The client was impressed with our unique capability (Automation & Modeling) which led to a discussion for a new scope of work.
